7. Output Power (distortion 10%) ≥ 450 mW

6. FM Stereo crosstalk > 35 dB

8. Station Memory 3050M in total

PER BAND AT PAGE "0" (total 650 memories)

- FM with 100 memories

- MW with 100 memories

- LW with 100 memories

- SW with 250 memories

- SBB with 100 memories

MIXTURE AT PAGE 1-24 (total 2400 memories)

11. Speaker: Diameter 40mm / Impedance 4 Ohm / Power 3W

12. Earphone Jack: Diameter 3.5mm

13. Power supply:

Rechargeable battery: Li-ion 3.7V

External adaptor: USB jack, DC 5V, Current >300mA

14. Unit Dimensions: approx. 192(W) X 113(H) X 33(D) mm

9. Alarm Mode: by Radio only

10. Quiescent Current

FM ＜ 30mA

MW/LW ＜ 70mA

SW ＜ 75mA

SSB ＜ 75mA

Off mode ＜ 80μA

15. Weight: 520g (battery not included)

PL-880 28
