Tektronix AFG31000 Series Service Manual

AFG31000 Series Arbitrary Function Generator Service Manual
10
Getting started
Thank you for choosing a Tektronix product. The AFG31000 Series Arbitrary Function Generator
(AFG) instruments are high-performance instruments with built-in waveform generation applications,
real-time waveform monitoring called InstaView
TM
, and an improved user interface for higher test
efficiency.
Contact information
If you have any questions after you review the information in this documentation, please contact your
local Tektronix office, sales partner, or distributor. You can also call the corporate headquarters of
Tektronix in North America at 1-800-833-9200. Visit tek.com
to find contacts in your area.
General model information
This manual provides operation information for the following products. Unless otherwise noted,
AFG31000 Series refers to the models in the following table.
Table 1: AFG31000 models
Model Bandwidth Sample rate Channel Waveform
memory size
Optional
AFG31021
25 MHz
250 MS/s
1
16 MS/CH
128 MS/CH
AFG31022
25 MHz
250 MS/s
2
16 MS/CH
128 MS/CH
AFG31051
50 MHz
1 GS/s
1
16 MS/CH
128 MS/CH
AFG31052
50 MHz
1 GS/s
2
16 MS/CH
128 MS/CH
AFG31101
100 MHz
1 GS/s
1
16 MS/CH
128 MS/CH
AFG31102
100 MHz
1 GS/s
2
16 MS/CH
128 MS/CH
AFG31151
150 MHz
2 GS/s
1
16 MS/CH
128 MS/CH
AFG31152
150 MHz
2 GS/s
2
16 MS/CH
128 MS/CH
AFG31251
250 MHz
2 GS/s
1
16 MS/CH
128 MS/CH
AFG31252
250 MHz
2 GS/s
2
16 MS/CH
128 MS/CH
Each AFG31000 Series provides:
 25 MHz to 250 MHz function signal generator
 20 MHz to 160 MHz pulse generator
The AFG31000 Series also provides 14-bit vertical resolution.
AFG31000 Series documentation
Complete documentation for the instruments is available at tek.com. The following table is a complete
list of available documentation.
Service introduction

Tektronix AFG31000 Series Specifications

General
