Page #27 background image
Adjustment procedures
27
AFG31000 Series Arbitrary Function Generator Service Manual
Equipment required
The next table lists the equipment that is required to complete the adjustment procedures.
Description Minimum requirements Recommended
equipment
Purpose
Digital multi meter
(DMM)
AC volts, true RMS, ac
coupled, Accuracy: ± 0.02% to
1 MHz, dc volts
Accuracy: 50 ppm, resolution
100 μV
Resistance accuracy: ± 0.05 Ω
Keithley 2002
Measures voltage; Used in
multiple procedures
Power meter
100 kHz to 250 MHz 1 μW to
100 mW (-30 dBm to +20
dBm)
Accuracy: 0.02 dB
Resolution: 0.01 dB
R&S NRP2
Measures voltage; Used in
multiple procedures
Power head
100 kHz to 250 MHz 1 μW to
100 mW (-30 dBm to +20
dBm)
R&S NRP6A
Measures voltage; Used in
multiple procedures
Frequency counter 50 kHz to 5 GHz, Accuracy:
0.01ppm Phase measurement
Tektronix
FCA3103
Checks clock frequency
Oscilloscope
1 GHz bandwidth 50 Ω input
termination
Tektronix
DPO7104C
Checks output signals;
Used in multiple procedures
Spectrum analyzer 20 kHz to 1.25 GHz
Tektronix
RSA5103
Checks output signals;
Harmonics Spurious
BNC coaxial cable
(2 required)
50 Ω, male to male
BNC connector, 91 cm
Tektronix part
number
012-0482-00
Signal interconnection
BNC terminator
50 Ω , ±1Ω , 2 W,
dc to 1 GHz, BNC
Tektronix part
number
011-0049-02
Signal termination
Adapter dual-
banana plug
BNC (female) to dual banana
Tektronix part
number
103-0090-00
Signal interconnection to a DMM
Adapter BNC(fe)-
N(ma)
BNC (female) to N (male)
Tektronix part
number
103-0045-00
Signal interconnection to a
Spectrum Analyzer
Performance conditions
The adjustments in this section are an extensive, valid confirmation of performance and functionality
when the following requirements are met:
The instrument covers must be on the AFG31000 Series.
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
The instrument must have had a warm-up period of at least 20 minutes.
