Tektronix AFG31000 Series Service Manual

Adjustment procedures
37
AFG31000 Series Arbitrary Function Generator Service Manual
15. Repeat steps 11 and 12, record the value from BIT1 to BIT9; each bit of the PI Command is
described below:
Bit PI command Adjust value
BITREF
MSERvice:DELYchip:BIT BITREF
Trefp
BIT0
MSERvice:DELYchip:BIT BIT0
T0p
BIT1
MSERvice:DELYchip:BIT BIT0
T1p
BIT2
MSERvice:DELYchip:BIT BIT0
T2p
BIT3
MSERvice:DELYchip:BIT BIT0
T3p
BIT4
MSERvice:DELYchip:BIT BIT0
T4p
BIT5
MSERvice:DELYchip:BIT BIT0
T5p
BIT6
MSERvice:DELYchip:BIT BIT0
T6p
BIT7
MSERvice:DELYchip:BIT BIT0
T7p
BIT8
MSERvice:DELYchip:BIT BIT0
T8p
BIT9
MSERvice:DELYchip:BIT BIT0
T9p
16. Send all the following PI commands to the DUT.
 MSERvice:DELYchip:VALUe BITREF,Trefp
 MSERvice:DELYchip:VALUe BIT0,T0p
 MSERvice:DELYchip:VALUe BIT1,T1p
 MSERvice:DELYchip:VALUe BIT2,T2p
 MSERvice:DELYchip:VALUe BIT3,T3p
 MSERvice:DELYchip:VALUe BIT4,T4p
 MSERvice:DELYchip:VALUe BIT5,T5p
 MSERvice:DELYchip:VALUe BIT6,T6p
 MSERvice:DELYchip:VALUe BIT7,T7p
 MSERvice:DELYchip:VALUe BIT8,T8p
 MSERvice:DELYchip:VALUe BIT9,T9p
 MSERvice:DELYchip:VALUe:APPLy
 MSERvice:CALibration:SAVE
