Tektronix AFG31000 Series Service Manual

Removal and installation
AFG31000 Series Arbitrary Function Generator Service Manual
65
Exploded diagram replaceable parts - module front chassis
Use the following table and figure to determine the replaceable parts and modules in your AFG
module front-chassis.
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-01
441-2877-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Chassis front
-02
878-1680-00
AFG31152
AFG31252
1
Circuit board assembly;
generator board; 2 CH;
389-5449-00 wired;
AFG31152/AFG31252
878-1487-00
AFG31021
AFG31051
AFG31101
1
Circuit board assembly;
generator board;
1 CH; 389-5224-00
wired, low-end models
878-1679-00
AFG31151
AFG31251
1
Circuit board assembly;
generator board;
1 CH; 389-5449-00
wired;
AFG31151/AFG31251
878-1490-00
AFG31022
AFG31052
AFG31102
1
Circuit board assembly;
generator board;
2 CH; 389-5224-00
wired; low-end models
-03
210-1700-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
BNC insulate washer
