Removal and installation
AFG31000 Series Arbitrary Function Generator Service Manual
75
Exploded diagram replaceable parts - module rear case
Use the following table and figure to determine the replaceable parts and modules in your AFG
module rear-case.
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-01
348-1909-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Foot, rear; safety
controlled
-02
348-1910-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Foot, front cabinet,
hinged
-03
214-5148-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Spring front foot
-04
202-0552-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Case, rear
