8. Quickly investigate your waveform by
moving from mark to mark with the Next
( →) or Prev (←) arrow button. No other
adjustments are needed.
9. To toggle between the display of search
events counts or Marks time, select the
Results tab and press View Count.
10. To export the Mark Table to a file, press
All Marks Export.
11. To convert a mark or all marks to user
marks, press Search Marks Save or
Save All.
12. To remove the currently highlighted row
from the Mark Table, press Search Marks
Clear.
13. To toggle between showing mark
locations in engineering notation or in
high precision form, press Digits.
14. To toggle the display of mark triangles on
and off, select the View tab and press
Show Marks.
Display a waveform
124 DPO70000SX Series User
