Power off the instrument
1. Press the front-panel power button to shut down the instrument.
NOTE. If powering off a multi-instrument configuration, power off the master first.
The shutdown process takes approximately 30 seconds to complete, placing the instrument in standby mode. Alternatively,
use the Windows Shutdown menu.
NOTE. You can force an immediate shutdown by pressing and holding the power button for four seconds. Unsaved data is
lost.
2. To completely remove power to the instrument, perform the shutdown just described, and then remove the power cord from
the instrument.
Multi-instrument configuration
Connect instruments in a multi-instrument configuration to create an up to 4 channel, highest bandwidth, and highest sample rate
system with synchronized trigger and sample clock.
Instrument stacking
Multiple instruments may be stacked to save space and allow shorter cables and more convenient connections.
WARNING. When using an instrument upside down, be careful to avoid pinching your fingers.
Install your instrument
10 DPO70000SX Series User
