Measurement Description
Ext Ratio (dB) The ratio of eye top to base expressed in decibels. This measurement only works for waveform
database or a reference waveform saved in waveform database mode.
Eye Height The measurement of the eye height in volts.
Eye Width The measurement of eye width in seconds.
Eye Top The top value used in the extinction ratio measurements.
Eye Base The base value used in the extinction ratio measurements.
Crossing % The eye crossing point expressed as a percentage of eye height.
Jitter P-P The peak-to-peak value for the edge jitter in the current horizontal units.
Jitter RMS The RMS value of the edge jitter in the current horizontal units.
Jitter 6 Sigma Six times the RMS value of the edge jitter in the current horizontal units.
Noise P-P The peak-to-peak value of the noise of the top or base of the signal as specified by you.
Noise RMS The RMS value of the noise of the top or base of the signal as specified by you.
S/N Ratio The ratio of the signal amplitude to the noise of the top or base of the signal as specified by
you.
Cyc Distortion The peak-to-peak time variation of the first eye crossing measured at the Mid Ref as a percent
of the eye period.
Q-Factor The ratio of eye size to noise.
Customizing an automatic measurement
Customize automatic measurements by using gating, modifying measurement statistics, or adjusting the measurement reference
levels.
Analyzing waveforms
DPO70000SX Series User 133
