Tektronix DPO70000SX Series User Manual

Noise (typical)
Gain setting, full
scale, BWE off
DPO77002SX,
DPO75902SX,
DPO75002SX,
DPO73304SX
TekConnect
channels
DPO72304SX DPO71604SX DPO71304SX
62.5 mV 0.88 mV 0.79 mV 0.74 mV 0.70 mV
100 mV 0.96 mV 0.86 mV 0.82 mV 0.79 mV
200 mV 1.53 mV 1.41 mV 1.30 mV 1.32 mV
500 mV 4.19 mV 3.14 mV 3.00 mV 3.05 mV
1 V 8.30 mV 6.10 mV 5.90 mV 6.08 mV
2.0 V 18.84 mV 14.19 mV 13.07 mV 13.09 mV
3.0 V 24.64 mV 19.09 mV 18.37 mV 18.37 mV
4.0 V 37.91 mV 26.01 mV 25.35 mV 25.55 mV
5.0 V 43.36 mV 31.84 mV 30.52 mV 30.62 mV
6.0 V 47.93 mV 36.97 mV 35.91 mV 36.33 mV
Gain
setting,
full scale,
BWE on
DPO77002SX,
DPO75902SX,
DPO75002SX,
DPO73304SX
TekConnect channels
DPO72304SX DPO71604SX DPO71304SX
100 GS/s 50 GS/s 100 GS/s 50 GS/s 100 GS/s 50 GS/s 100 GS/s 50 GS/s
62.5 mV 0.84 mV 0.84 mV 0.75 mV 0.72 mV 0.78 mV 0.77 mV 0.71 mV 0.69 mV
100 mV 0.93 mV 0.93 mV 0.78 mV 0.82 mV 0.77 mV 0.81 mV 0.68 mV 0.73 mV
150 mV 1.31 mV 1.29 mV 1.08 mV 1.19 mV 0.94 mV 1.01 mV 0.88 mV 0.95 mV
200 mV 1.52 mV 1.60 mV 1.14 mV 1.43 mV 1.04 mV 1.18 mV 0.99 mV 1.14 mV
300 mV 2.49 mV 2.52 mV 2.10 mV 2.29 mV 1.58 mV 1.8 mV 1.57 mV 1.79 mV
400 mV 2.92 mV 3.12 mV 2.58 mV 2.29 mV 1.82 mV 2.20 mV 1.82 mV 2.21 mV
500 mV 3.55 mV 3.80 mV 2.65 mV 3.38 mV 2.17 mV 2.66 mV 2.2 mV 2.69 mV
600 mV 4.86 mV 4.86 mV 4.14 mV 4.42 mV 3.02 mV 3.46 mV 3.01 mV 3.43 mV
700 mV 5.25 mV 5.39 mV 4.64 mV 4.96 mV 3.28 mV 3.85 mV 3.25 mV 3.80 mV
800 mV 5.76 mV 6.08 mV 5.08 mV 5.52 mV 3.61 mV 4.37 mV 3.56 mV 4.29 mV
900 mV 6.30 mV 6.66 mV 5.63 mV 6.13 mV 3.96 mV 4.81 mV 3.89 mV 4.69 mV
1 V 6.80 mV 7.30 mV 5.09 mV 6.54 mV 4.29 mV 5.29 mV 4.2 mV 5.14 mV
1.1 V 8.69 mV 9.02 mV 7.79 mV 8.20 mV 5.48 mV 6.94 mV 5.45 mV 6.74 mV
1.2 V 9.12 mV 9.60 mV 8.28 mV 8.72 mV 5.75 mV 7.50 mV 5.73 mV 7.28 mV
2.0 V 15.40 mV 14.53 mV 11.66 mV 14.65 mV 9.70 mV 12.23 mV 9.88 mV 11.87 mV
3.0 V 19.91 mV 19.82 mV 15.31 mV 20.51 mV 12.98 mV 16.55 mV 13.19 mV 16.81 mV
4.0 V 28.83 mV 27.85 mV 21.61 mV 27.84 mV 19.56 mV 23.17 mV 18.64 mV 21.32 mV
5.0 V 34.32 mV 32.80 mV 25.69 mV 34.07 mV 22.82 mV 27.79 mV 21.82 mV 26.03 mV
6.0 V 39.82 mV 38.96 mV 29.65 mV 39.18 mV 26.65 mV 32.42 mV 25.74 mV 31.45 mV
Specifications Vertical system analog channels (cont.)
190 DPO70000SX Series User

Tektronix DPO70000SX Series Specifications
