Tektronix DPO70000SX Series User Manual

Edge trigger sensitivity DC
coupled (typical)
All sources, positive or negative edge.
Trigger Source Sensitivity
A-Event trigger ≤ 5%FS from DC to 50 MHz
≤ 7.5%FS at 5 GHz
≤ 10%FS at 10 GHz
≤ 15%FS at 15 GHz
≤ 35%FS at 20 GHz
≤ 50%FS at 25 GHz
B-Event trigger ≤ 5%FS from DC to 50 MHz
≤ 7.5%FS at 5 GHz
≤ 10%FS at 10 GHz
≤ 15%FS at 15 GHz
≤ 35%FS at 20GHz
≤ 50%FS at 25 GHz
Auxiliary input 100 mV
pp
from DC to 1 GHz
175 mV
pp
at 4 GHz
225 mV
pp
at 8 GHz
450 mV
pp
at 10 GHz
800 mV
pp
at 11 GHz
Time-qualified trigger timer
accuracy
For glitch, width, time qualified runt, transition, or window and timeout triggering (40 ps to 1.0 ns
typical):
Time range Accuracy
40 ps to ≤50 ns ±(3% of setting + 15 ps)
40 ps to ≤1 ns ±(3% of setting + 15 ps) (typical)
1 ns to ≤50 ns ±(3% of setting + 15 ps)
500 ns to 1 s ±(150 ppm x setting + 500 ps)
Setup/hold violation and time qualified pattern (40 ps to 1.0 ns typical):
300 ps to 1.01 μs ±(5% of setting + 200 ps)
1.02 μs to 1 s ±(TB
1
accuracy + 20 ns)
Trigger jitter DC coupled A edge
(typical)
10 fs using enhanced trigger placement.
1 ps rms for low frequency, fast rise time signal, A edge, holdoff time = 30 μs
1
TB Accuracy is the Time Base Accuracy expressed as a percentage of setting
Trigger specifications (cont.) Specifications
DPO70000SX Series User 193
