Tektronix DSA8200 Series User Manual

Command Groups
Command
Description
TRIGger:CLKRec:CRC:DELETESTandard Deletes the named standard from the
connected Clock Recovery instrument
TRIGger:CLKRec:CRC:DEVICEName Sets or queries the device name of the
connected Cl
ock Recovery instrument
TRIGger:CL
KRec:CRC:EDGEDensity?
Returns the
measured edge density (in
percent) from the connected Clock Recovery
instrument
TRIGger:CLKRec:CRC:
EDGEDENSI
TYMode
Sets or queries the edge density mode
setting of
the connected Clock Recovery
instrument
TRIGger:CLKRec:CRC:EQUalizer Sets or queries the CR286A clock recovery
instrument equalizer value.
TRIGger:CLKRec:CRC:EXPrev?
Returns the expansion board revision string
of the connected Clock Recovery instrument
TRIGger:CLKRec:CRC:FPGarev? Returns the FPGA revision string of the
connect
ed Clock Recovery instrument
TRIGge
r:CLKRec:CRC:HALfrate?
Returns the clock recovery device clock rate.
TRIGg
er:CLKRec:CRC:HWRev?
Retur
ns the hardware revision string of the
connected Clock Recovery instrument
TRIGger:CLKRec:CRC:LOCKCount? Returns the number of times the connected
Clock Recovery instrument has relocked
sinc
e the last reset
TRIG
ger:CLKRec:CRC:LOCKFp
Locks or unlocks the clock recovery
inst
rument front panel controls.
TRI
Gger:CLKRec:CRC:LOCKMode
Set
s or queries the lock mode of the
connected Clock Recovery instrument
TRIGger:CLKRec:CRC:LOCKRange Sets or queries the locking range about the
nominal frequency setting of the connected
Cl
ock Recovery instrument
T
RIGger:CLKRec:CRC:LOCKState?
R
eturns the lock state of the connected
Clock Recovery instrument
TRIGger:CLKRec:CRC:LOOPBandwidth Sets or queries the loop bandwidth of the
connected Clock Recovery instrument
TRIGger:CLKRec:CRC:MODElnum?
Returns a string with the clock recovery
instrument identifier information.
TRIGger:CLKRec:CRC:NOMEDgedensity Sets or queries the nominal edge density of
the connected Clock Recovery instrument
TRIGger:CLKRec:CRC:NOMFrequency Sets or queries the nominal frequency setting
of the connected Clock Recovery instrument
TRIGger:CLKRec:CRC:PEAKing Sets or queries the peak range of the
connected Clock Recovery instrument
TRIGger:CLKRec:CRC:PHASEERRLimit Sets or queries the phase error limit of the
connected Clock Recovery instrument
2-38 DSA/CSA/TDS8X00/B Series Programmer Manual
