2260B Series User Manual
78
Internal Resistance
 Only the master unit’s internal resistance
settings apply.
 For 2 units in parallel, the internal resistance is
actually half of the setting value.
 For 3 units in parallel, the internal resistance is
actually a third of the setting value.
Bleeder Control
 The Master unit is used to control the bleeder
settings. The bleeder resistors in all the slave
units are always turned off when in parallel
mode.
Output Voltage/
Output Current
Model
Single unit
2 units
3 units
2260B-30-36
30V
36A
30V
72A
30V
108A
2260B-80-13
80V
13.5A
80V
27A
80V
40.5A
2260B-250-4
250V
250V
250V
4.5A
9A
13.5A
2260B-800-1
800V
800V
800V
1.44A
2.88A
4.32A
2260B-30-72
30V
30V
30V
72A
144A
216A
2260B-80-27
80V
80V
80V
27A
54A
81A
2260B-250-9
250V
250V
250V
9A
18A
27A
2260B-800-2
800V
800V
800V
2.88A
5.76A
8.64A
2260B-30-108
30V
30V
30V
108A
216A
324A
2260B-80-40
80V
80V
80V
40.5A
81A
121.5A
2260B-250-13
250V
250V
250V
13.5A
27A
40.5A
2260B-800-4
800V
800V
800V
4.32A
8.64A
12.96A
