Section 3: Keithley Configuration Utility (KCon) Model 4200A-SCS Setup and Maintenance User's Manual
3-4 4200A-908-01 Rev. A December 2020
Add an external instrument
To add a supported external instrument to the system configuration, select Add External Instrument.
The supported instrument categories are:
• Switch Matrix
• Capacitance Meter
• Pulse Generator
• Probe Station
• Test Fixture
• General Purpose Test Instrument
Supported external instrumentation and equipment are controlled by Clarius user test modules
(UTMs). Keithley Instruments provides libraries of user modules for each supported external
instrument (refer to Supported external equipment (on page 3-6)).
You can modify these libraries or create your own using the Keithley User Library Tool (KULT). For
additional information, refer to Keithley User Library Tool.
The following figure shows the relationship between internal and external instrumentation and
illustrates each instrument category.
