Model 4200A-SCS Setup and Maintenance User's Manual Section 5: System administration

4200A-908-01 Rev. A December 2020 5-7

Restoring the 4200A-SCS hard drive to factory condition deletes all files written to the hard

drive after shipment. Ensure you back up all data and files before you restore the hard drive

to factory condition.

To restore the 4200A-SCS hard drive to factory condition:

1. Reboot the 4200A-SCS. As the system boots up, there is a splash screen that contains the

Keithley logo.

2. In the upper-left corner, either a prompt or menu with options is displayed depending on your

4200A-SCS version.

a. If you see Press F11 to run Acronis Startup Recovery Manager..., press the F11 key to begin

the recovery process.

b. If you see Select an item by using the keyboard: followed by multiple options, press the 1 key

to begin the recovery process.

You have approximately five seconds to press a key. Otherwise, Windows

will begin to boot.

3. Follow the instructions to restore the factory hard drive image.

For additional detail about the Acronis True Image HD software, please refer to the Acronis True

Image OEM User Guide, available from The Learning Center.

Choose the files to be backed up

Keithley recommends backing up the following files and directories, where applicable:

• The default user directory

When a 4200A-SCS is received from the factory, the C:\s4200\kiuser directory contains all

installed test results and user application files. Clarius

stores all user-created projects and tests

in this location.

Avoid selective backups of C:\...\data subfolders, such as

C:\s4200\kiuser\Projects\default\tests\data . Such backups do not preserve the

additional application files that are needed to restore the associated test setups and conditions.

• Special data files and directories

Back up any additional, specialized data files or directories, such as the following:

▪ A file into which a User Test Module (UTM) automatically places test results. For example, a

UTM could be set to put results into C:\TestData\test001.dat.

▪ A file that results from manual processing of data using Microsoft

Excel
