Section 3: Keithley Configuration Utility (KCon) Model 4200A-SCS Setup and Maintenance User's Manual
3-6 4200A-908-01 Rev. A December 2020
Supported external equipment
Keithley Instruments provides a number of standard user libraries to control external equipment that is
typically used in semiconductor characterization applications. Standard user-module libraries are
provided for the equipment shown in the following table.
Supported external equipment
Category
Instrument
User library
Additional information
Switch matrix
1
Series 700 Switching System
Matrixulib
“Using Switch Matrices” in Model
4200A-SCS Prober and External
Instrument Control
Capacitance
meter
2
Keithley Instruments Model 590 CV
Analyzer
KI590ulib
“Using a Model 590 CV Analyzer” in
Model 4200A-SCS Prober and
External Instrument Control
Keithley Instruments Model 595
Quasistatic C-V Meter
KI595ulib
Model 595 Quasistatic C-V Meter
Instruction Manual (document
number 595-901-01)
Keithley Instruments Model 82
Simultaneous C-V System
ki82ulib
“Using a Keithley Model 82 C-V
System” in Model 4200A-SCS Prober
and External Instrument Control
Keysight Technologies 4284 or 4980
LCR Meter
HP4284ulib
“Using a Keysight 4284/4980A LCR
Meter” in Model 4200A-SCS Prober
and External Instrument Control
Keysight Model 4294 LCZ Meter
HP4294ulib
“HP4294ulib user library reference” in
the Model 4200A-SCS Clarius User's
Manual
Pulse
generator
3
Keithley Instruments Model 3402
Pulse Generator
ki340xulib
Series 3400 Pulse Pattern
Generators User’s Manual (document
number 3400S-900-01)
Keysight Model 8110A Pulse
Generator
HP8110ulib
“Using a Keysight 8110A/81111A
Pulse Generator” in Model
4200A-SCS Prober and External
Instrument Control
Probe station
4
Karl Suss MicroTec Model PA-200
semiautomatic probe station
PRBGEN
“Suss MicroTec PA-200 Prober” in
Model 4200A-SCS Prober and
External Instrument Control
Micromanipulator Model 8860
semiautomatic probe station
PRBGEN
“Micromanipulator 8860 Prober” in
Model 4200A-SCS Prober and
External Instrument Control
Manual probe station and fake probe
station
PRBGEN
“Using a Manual or Fake Prober” in
Model 4200A-SCS Prober and
External Instrument Control
Cascade Summit-12000 probe station
PRBGEN
“Cascade Summit-12000 Prober” in
Model 4200A-SCS Prober and
External Instrument Control
Signatone CM500 Prober
PRBGEN
“Signatone CM500 Prober” in Model
4200A-SCS Prober and External
Instrument Control
MPI Probers TS2000, TS2000-DP,
TS2000-HP, TS2000-SE, TS3000,
and TS3000-SE.
PRBGEN
“Using an MPI Probe Station” in
Model 4200A-SCS Prober and
External Instrument Control
