Section 3: Keithley Configuration Utility (KCon) Model 4200A-SCS Setup and Maintenance User's Manual
3-12 4200A-908-01 Rev. A December 2020
Summary
The Summary displays the system configuration. From this display, you can save the configuration or
print it.
The sections of the system configuration are:
• System Information: Provides a table containing the 4200A-SCS serial number, the network or
system name, and pertinent software and platform version information.
• Instrumentation: Provides a table of properties and settings for each instrument in the system
configuration.
• Connections: Provides a table of system connections. The connection table provides guidance
when making connections between the instrumentation and an optional switch matrix and test
fixture or probe station.
To save the files in html format, select Save Configuration As. You can view the html file in a
web browser.
To print the configuration, select Print Configuration.
System Configuration properties
Each instrument that is included in the system is displayed in the System Configuration list. When you
select an item from the list, the corresponding properties are displayed in the Properties area. The
following topics describe the properties for each supported instrument.
KI 4200A SCS Properties
When you select 4200A-SCS in the System Configuration list, the Properties of the 4200A-SCS are
displayed, as shown in the figure below.
Figure 18: 4200A-SCS Properties
