About This Guide
Begin by exploring the controls and display of the
TBS2000B Series. Then move on to a series of hands-
on exercises.Acquire waveforms, learn about triggering,
take measurements, and learn how to save data. Get an
introduction to the TBS2000B’s connectivity and remote
control capabilities, and tools for education.
◦ TBS2000B Series Oscilloscope
◦ Power Cord for your region (included with
instrument)
◦ Two TPP0100 or TPP0200 passive probes
with hook tips attached (included with
instrument)
◦ AUSB flash drive (to demonstrate screen image
capture)
◦ TEKUSBWIFI USB Wi-Fi dongle (to demonstrate
wireless communications)
◦ PC with Ethernet connection (to demonstrate
remote control)
◦ Ethernet cable (to demonstrate remote control)
Required Equipment
4
