Status and Events

TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer

3-19

Table 3- 5: Execution error messages – EXE bit 4 (Cont.)

Code Message

211 Trigger ignored

212 Arm ignored

220 Parameter error

221 Settings conflict

222 D ata out of range

223 Too much data

224 Illegal parameter value

230 D ata corrupt or stale

240 H ardware error

241 Hardware missing

242 H ardware configuration error

243 H ardware I/O device error

250 Mass storage error

251 Missing mass storage

252 Missing media

253 C orrupt media

254 Media full

255 D irectory full

256 File name not found

257 File name error

258 Media protected

260 Expression error

261 Math error in expression

2200 Measurement error , Measurement system error
