Command Descriptions

TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer

2-61

You can only send synchronization commands or queries (such as

*OPC, OPC?, *WAI, BUSY?) whil e doing a fact ory ca libration.

Calibration and Diagnostic

CALibrate:FACtory

Starts the factory calibration process.

CALibrate:INTERNAL (Set Only)

Performs an internal self-calibration but does not return any status.

This is equivalent to selecting the Do Self Cal option in the Utility

menu.

NOTE. The self-calibration can take several minutes to complete.

During this time, the oscilloscope does not execute any commands.

Disconnect all signals from the oscilloscope before performing an

internal self-calibration.

CALibrate:INTERNAL

Performs an internal self-calibration.

*CAL?

Group

Syntax

Examples

Syntax

Examples

Related Commands
