Tektronix TDS6000 Series Reference Manual

Front Panel Inputs and Outputs
Floppy disk drive accessible
from Windows
Ground terminal
Channel inputs
Recovered clock output
Recovered data output
Optical input to O/E converter
Probe compensator output to compensate
and deskew probes
Electrical output from O/E converter
CSA7404
CSA7154
Floppy disk drive accessible
from Windows
TDS6404
TDS6604
TDS7404
TDS7254
TDS7154
Ground terminal
Channel inputs
Auxiliary input to provide an external
trigger input
Auxiliary output to provide trigger
output signal
Analog signal output from the CH 3 input
Probe compensator output to compensate
and deskew probes
Floppy disk drive accessible
from Windows
TDS7104
TDS7054
Ground terminal
Channel inputs
Auxiliary input to provide
an external trigger input
Auxiliary output provides trigger
output signal
Analog signal output from the CH 3 input
Probe compensator output to
compensate and deskew probes.
