Section 1 - Introduction and Specification
1-4
VM700A Option 01 (NTSC) & Option 11 (PAL) User Manual
Table 1-4: Remote Relay (Cont.)
Characteristics Description
Maximum Voltage 30 VAC
RMS
or 30 VDC
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Control Logic
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁ
Á
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
set GRLY 1 closes the relay.
set GRLY 0 opens the relay.
Table 1-5: Optional Power Cords
Power Plugs Description Reference Standards
1
Standard
North American
120 V plug
15 A
ANSI C73.11
NEMA 5-15-P
IEC 83
UL 198.6
Option A1
Universal Euro
220 V plug
10-16 A
CEE(7)
II, IV, VII
IEC 83
IEC 127
Option A2
2
United Kingdom
240 V plug
6 A
BS 1363
IEC 83
IEC 127
Option A3
Australian
240 V plug
10 A
AS C112
IEC 127
Option A4
North American
240 V
15 A
ANSI C73.20
NEMA 6-15-P
IEC 83
UL 198.6
Option A5
Switzerland
220 V plug
6 A
SEV
IEC 127
1
Reference Standards Abbreviations:
ANSI—American National Standards Institute
AS—Standards Association of Australia
BS—British Standards Institution
CEE—International Commission on Rules for the Approval of Electrical Equipment
IEC—International Electrotechnical Commission
NEMA—National Electrical Manufacturer’s Association
SEV—Schwetzervischer Elektrotechischer Versin
UL—Underwriters Laboratories Inc.
2
A 6 A, type C fuse is also installed inside the plug of the Option A2 power cord.
