Tektronix WFM6120 Service Manual

General Maintenance
Optional board
s:
Physical layer, for Option EYE/PHY
3G Physical layer, for Option 3G/JIT
Composite input, for Option CPS
Audio Main, for Option AD and DDE
Analog Audio, for Options AD and DDE
Dolby Deco
der module, for Option DDE
Table 4-3: Required test equipment
Test equipm ent Requirements Example
1080i 59.94 HD signals required for
WFM7x00OptionHD:
100% color bars
10 bit shallow ramp
SDI M atrix Split Field Pathological
Signal
100% sweep
Tektronix TG2000 with HDVG1 module
for TG2000 (Embedded audio needed for
audio options)
525/270 SD signals required for
WFM7120 Option SD and WFM6120
Option SD:
100% color bars
10 bit shallow ramp
SDI Matrix Pathological Signal
100% sweep
DVG1 with option S1 module for TG2000
(Embedded audio needed for audio
options)
Composite signals required for Option
CPS: NTSC SMPTE bars
AVG1 module for TG2000
SDI serial digital video test generator with
embedded audio and composite signal
source.
Varies with installed options:
SD - need SD SDI source
HD - Need HD SDI source
CPS - Need composite SDI source
Precision calibration signals for Option
CPS
067-0465-00 calibration fixture for
TG2000
XGA Monitor Computer monitor capable of 1024 x 768
x60Hzscanrate
AES Audio Signal Generator (If any audio
option installed)
48 kHz, 24 bit w ord length signals
Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
Analog Audio Signal Generator (If any
audio option installed)
Rohde & Schwarz UPL06, Tektronix
AM700 and AM70.
Voltmeter Fluke 87 or equivalent
DC Ammeter with Clamp on pickup 20 Amp DC capable
Fluke 336 or equivalent
Oscilloscope
Video trigger capability
Tektronix TDS3000C Series
4–6 WFM6120, WFM7020, and WFM7120 Waveform Monitors Service Manual
