Tektronix WFM6120 Service Manual

Replaceable Parts
Table 5-4: Repl
aceable parts list (See Figure 5-4.)
Fig. &
index
number
Tektronix par
t
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-4 Main Board
-1 159-5022-00
7
FUSE; 5.0A,125V;FAST BLOW,0.1 X 0.1 X 0.24,UL REG,CSA
CERT;451005,SAFETY CONTROLLED
-2 260-5015-00 1
SWITCH, PUSH; SPST, TACT;50MA, 50V, MOMENTARY, SILVER
CONTACTS;KSC221G, GULLWING SMD
-3 159-5018-00 1
FUSE; 3.0A,125V,FAST BLOW,0.1 X 0.1 X 0.24,UL REG,CSA
CERT,SAFETY CONTROLLED
-4 159-5003-00 1
FUSE,THRM,CHIP; SELF RESETTING FUSE,1.1A HOLD,2.2A TRIP AT
20 DEG C,30V MAX,SAFETY CONTROLLED
-5
159-5014-00 1
FUSE; 2.0A,125V,FAST BLOW,0.1 X 0.1 X 0.24,UL REG,CSA
CERT,SAFETY CONTROLLED
5–10 WFM6120, WFM7020, and WFM7120 Waveform Monitors Service Manual
