Tektronix WFM6120 Service Manual

Removal and Replacement Procedures
Removal and Replacement Procedures
This section contains information about removal and replacement of all modules
in the waveform monitor.
Preparation
WARNING. Before doing this or any other p rocedure in this manual, read the
safety summaries found at the beginning of this manual. Also, to prevent possible
injury to service personnel or damage to the instrument components, read
Installation in Section 2, and Preventing ESD in this section.
This subsection contains the following items:
This preparatory information that you need to properly do the procedures
that follow.
List of tools required to remove and disassemble all modules.
Procedures for removal and reinstallation of the modules.
WARNING. Before doing any procedure in this subsection, disconnect the power
cord from the line voltage source. Failure to do so could cause serious injury
or death.
NOTE. Read Equipment Required for a list of the tools needed to remove and
install modules in this instrument. (See Table 4-9 on page 4-27.) Read the
cleaning procedure before disassembling the instrument for cleaning.
Equipment Required. Most modules in the instrument can be removed with a
screwdriver handle mounted with a size T-10, Torx screwdriver tip. All equipment
required to remove and reinstall the modules is listed in the following table. (See
Table 4-9 on page 4-27.)
Table 4-9: Tools required for module removal
Item
no. Name Description
General Tool
number
1
Screwdriver handle
Accepts Torx-driver bits 620-440
2T-10Torxtip
Used for removing most instrument
screws. Torx-driver bit for T-10 size
screw heads
640-235
WFM6120, WFM7020, and WFM7120 Waveform Monitors Service Manual 4–27
