Field Description
Possible values:
• -,, (default value): The filter is valid for all port numbers
• *)"!& ): Enables the entry of a port number.
• *)"!& ) : Enables the entry of a range of port
numbers.
Source IP Address/
Netmask
Enter the source IP address and netmask of the data packets.
Source Port/Range
Only if Protocol = (2, 0.
Enter a source port number or the range of source port num-
bers.
Possible values:
• -,, (default value): The filter is valid for all port numbers
• *)"!& ): Enables the entry of a port number.
• *)"!& ) : Enables the entry of a range of port
numbers.
DSCP/TOS Filter
(Layer 3)
Select the Type of Service (TOS).
Possible values:
• (default value): The type of service is ignored.
• .*2 =& 6,3: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in binary format, 6 bit).
• .*2 .", 6,3: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in decimal format).
• .*2 ?<", 6,3: Differentiated Services Code
Point according to RFC 3260 is used to signal the priority of
IP packets (indicated in hexadecimal format).
• (:* =& 6,3: The TOS value is specified in binary
format, e.g. 00111111.
• (:* .", 6,3: The TOS value is specified in decimal
format, e.g. 63.
• (:* ?<", 6,3: The TOS value is specified in
hexadecimal format, e.g. 3F.
Teldat GmbH
14 Networking
bintec Rxxx2/RTxxx2 231
