Property bintec R1202 bintec RT1202
Dimensions and weights:
Equipment dimensions
without cable (B x H x D):
19" housing (482.6 mm x 220 mm
x 45 mm)
19" housing (482.6 mm x 220 mm
x 45 mm)
Weight approx. 2.0 kg approx. 2.0 kg
Transport weight (incl. doc-
umentation, cables, pack-
aging)
approx. 2.6 kg approx. 2.6 kg
Memory 64 MB RAM,
16 MB flash ROM
64 MB RAM,
16 MB flash ROM
LEDs 13 (1x Power, 1x Status, 5x2 Eth-
ernet, 1x Function)
14 (1x Power, 1x Status, 5x2 Eth-
ernet, 2x Function)
Power consumption of the
device
max. 15 Watt, normally 13 Watt max. 15 Watt, normally 13 Watt
Voltage supply Voltage Range 85 ~ 264 V AC
Frequency Range 47 ~ 63 Hz
Efficiency (Typ.) 79 %
Voltage Range 85 ~ 264 V AC
Frequency Range 47 ~ 63 Hz
Efficiency (Typ.) 79 %
Environmental require-
ments:
Storage temperature -25 °C to +70 °C -25 °C to +70 °C
Operating temperature 0 °C to +40 °C 0 °C to +40 °C
Relative atmospheric hu-
midity
10 % to 90 % non-condensing in
operation,
5 % to 95 % non-condensing when
stored
10 % to 90 % non-condensing in
operation,
5 % to 95 % non-condensing when
stored
Room classification Only use in dry rooms. Only use in dry rooms.
Available interfaces:
Ethernet IEEE 802.3 LAN
(4-port switch)
Permanently installed (twisted pair
only), 10/100/1000 mbps, auto-
sensing, MDIX
Permanently installed (twisted pair
only), 10/100/1000 mbps, auto-
sensing, MDIX
5 Technical data Teldat GmbH
14 bintec Rxxx2/RTxxx2
