Field Description
Bridged Ethernet with LLC/SNAP encapsulation with Frame
Check Sequence (checksums).
• ' *: (default value for Routed Protocols over ATM): Is
only displayed for Type = @3 ",# -(%.
Encapsulation with LLC/SNAP header, suitable for IP routing.
• //2: only displayed for Type = -(%.
Encapsulation with LLC header.
• 62 %3,),< (default value for PPP over ATM):
Bridged Ethernet without additional encapsulation (Null En-
capsulation) with Frame Check Sequence (checksums).
Fields in menu Ethernet over ATM Settings (appears only for Type = Ethernet over
ATM)
Field Description
Default Ethernet for
PPPoE Interfaces
Only for Type = -(%
Select whether this Ethernet-over-ATM interface is to be used
for all PPPoE connections
The function is enabled with ,.
The function is disabled by default.
Address Mode Only for Type = -(%
Select how an IP address is to be assigned to the interface.
Possible values:
• *" (default value): The interface is assigned a static IP
address in IP Address / Netmask.
• .?2: An IP address is assigned to the interface dynamically
via DHCP.
IP Address/Netmask Only for Address Mode = *"
Enter the IP addresses (IP Address) and the corresponding
netmasks (Netmask) of the ATM interfaces. Add new entries
with Add.
Teldat GmbH
17 WAN
bintec Rxxx2/RTxxx2 307
