Field Description
Connection Type Select whether the L2TP partner is to take on the role of the
L2TP network server (LNS) or the functions of a L2TP access
concentrator client (LAC client).
Possible values:
• /'* (default value): If you select this option, the L2TP partner
is configured so that it accepts L2TP tunnels and restores the
encapsulated PPP traffic flow.
• /-2: If you select this option, the L2TP partner is configured
so that it encapsulates a PPP traffic flow in L2TP and sets up
a L2TP tunnel to a remote LNS.
Tunnel Profile Only for Connection Type = /-2
Select a profile created in the Tunnel Profile menu for the con-
nection to this L2TP partner.
User Name Enter the code of your device.
Password Enter the password.
Always on Select whether the interface should always be activated.
The function is enabled with ,.
The function is disabled by default.
Connection Idle
Timeout
Only if Always on is disabled
Enter the idle time in seconds for static short hold. The static
short hold setting determines how many seconds should pass
between sending the last traffic data packet and clearing the
connection.
Possible values are to $ (seconds). deactivates the
short hold. The default value is $.
Fields in the IP Mode and Routes menu.
Field Description
IP Address Mode Select whether your device is to be assigned a static IP address
or whether it should be assigned this dynamically.
18 VPN Teldat GmbH
366 bintec Rxxx2/RTxxx2
