37
Addr
Inst
R/W
Host
R/W
Range
Description
$06 ClO
2
Chlorine Dioxide
$07 HCN Hydrogen Cyanide
$08 PH
3
Phosphine
$09 H
2
Hydrogen
$0B CO
2
Carbon Dioxide
$0C NO Nitric Oxide
$0D NH
3
Ammonia
$0E HCl Hydrogen Chloride
$14 O
2
Oxygen
$15 CH
4
Methane
$16 LEL Lower Explosive Limit
(Combustible Gases)
$17 C
6
H
14
Hexane
$1A C
5
H
12
Pentane
$1B C
3
H
8
Propane
$4D C
2
H
6
O Ethanol
$50 C
2
H
4
Ethylene
$6F C
3
H
6
Propylene
$C9 C
4
H
10
Butane
Examples:
$0107 = 1 decimal place for gas type HCN
$0002 = 0 decimal places for gas type H
2
S
$0206 = 2 decimal places for ClO
2
40105 W R/W $0000 to $FFFF
Instrument Mode
Holds code for current mode of instrument. Possible working modes of instrument are
listed below.
$0001 Normal
$0002 Calibration
$0003 Warm-up
$0006 Zeroing
$0008 Fault
$0009 Reset
Examples:
Sensor in zero fault = $0008
Sensor zeroing = $0006
40106 W R $0000 to $FFFF
Status Bits
Holds 16 bits of status for various parameters in the instrument. A bit value of “1”
indicates that the associated fault condition is present.
Bit 15 = current loop open
Bit 14 = current loop shorted
Bit 13 = power fault
Bit 12 = 5 volt fault
Bit 11 = missing sensor
Bit 10 =
(not defined)
Bit 6 = configuration fault
Bit 5 = zero fault
Bit 4 = calibration fault
Bit 3 = over-range
Bit 2 = failed sensor
Bit 1 = high alarm
Bit 0 = low alarm
Examples:
Missing sensor = Bit 11 is set = $0800
Power fault and
failed sensor = Bits 13 and 2 set= $2004
40115 W R
Last Alarm Date (mmdd)
Holds the month and day when the instrument had the last alarm.
High byte = $01 to $0C
Low byte = $01 to $1F
Examples:
