TELEDYNE OLDHAM SIMTRONICS iTRANS 2 - 8.2 Fault and Function Codes

iTRANS 2
FIXED POINT SINGLE OR DUAL GAS MONITOR
WITH DUAL ANALOG OUTPUTS
USER MANUAL
44
77036429-EN
Revision 7.0
8.3 Fault Codes
Fault
Display
Status
Bit
4-20 mA Output
Description
0.FFF Flashing 1 mA Zeroing error – Recover after calibrating
C.FFF Flashing 1 mA
Calibration error – Recover after calibrating or
replacing the sensor
1.FFF Flashing 1 mA SMART sensor error
2.FFF Flashing 1 mA Sensor error
U-Or Flashing 1mA Sensor under-range
U Or Flashing
22mA for ~5 seconds then settled at
1mA
Sensor over-range
Table 8-2 Fault Codes
8.4 Function Codes
Function Code
LED Display
Description
Status Bit
Data Area
L L. Low Alarm Set the relay low alarm value
H H. High Alarm Set the relay high alarm value
4 4. Range of 4-20 mA Set the range of 4-20 mA output
1 1. Minute Set system time – minute
H h. Hour Set system time – hour
D d. Date Set system time – date
E E. Month Set system time – month
8 8. Year Set system time – year
0 0. Zeroing
C C. Calibration
S S. Span Gas Concentration Set span gas concentration
R r. Sensor Span Reserve Check the span reserve
2 2. Date The latest alarm time-date
3 3. Month The latest alarm time-month
6 6. Date The latest calibration time-date
7 7. Month The latest calibration time-month
9 9. Year The latest calibration time-year
Table 8-3 Function Codes
