3 Installation
3.1 Introduction
The can be mounted in one of two ways. The unit can be wall-mounted using the wall
mounting holes in the enclosure, or it can be mounted onto a column using U-bolts. Each of these
options is discussed in this chapter. Be sure to review the installation considerations before
mounting the gas monitor.
3.2 Installation Considerations
Regardless of the installation type (wall mounting or column mounting), the should be
installed at or near the location of a possible leak or the source of emissions. Installation height
depends on the density of the gas being monitored. Moreover, speed and direction of air flow,
and relative position to potential leaking points should also be considered.
IMPORTANT: The gas monitor must not be installed on vibrating or heat generating
sources.
3.3 Wall Mounting
If your application is best addressed using a wall-mounted gas monitor, then use the four 8 mm
mounting holes in the enclosure to secure the to an appropriate location on the wall. Refer
to Figure 3-1.
3.4 Column Mounting
If your application is best addressed using a column-mounted gas monitor, then use the four 8
mm mounting holes and two U-bolts to secure the to an appropriately located segment
of a target pipe or conduit. Refer to Figure 3-2.
