2 Hardware Overview
2.1 Main Electronics Unit (Housing)
The body is a cast aluminum housing that contains the electronics of the gas monitor.
Details of a single-gas housing are shown in
Figure 2-1.
Figure 2-1 Details of a Single-Gas Gas Monitor
