Teledyne 300E - A1 & A2 Single Range Mode

Model 300E Carbon Monoxide Analyzer
Instruction Manual
Operating Instructions
P/N 04288 REV: A 65
To select the Analog Output Range Type press:
SAMPLE RANGE = 50.0 PPM CO =
< TST TST > CAL
SETUP
SETUP C.3
CFG DAS
RNGE
PASS CLK MORE EXIT
SETUP C.3 RANGE CONTROL MENU
MODE
SET UNIT EXIT
EXIT Returns
to the Main
SAMPLE
Display
Go To
Section
6.4.3
Go To
Section
6.4.4
Go To
Section
6.4.5
SETUP C.3 RANGE MODE: SNGL
SNGL DUAL AUTO ENTR EXIT
6.4.3. A1 & A2 Single Range Mode
This is the default Measurement Range mode for the analyzer. In this mode, both
analog outputs (A1 and A2) are set to the same range. This Measurement Range
can be set to any value between 1.0 and 1,000 ppm and is accessed through the
following keystroke sequence:
