D Series Syringe Pumps
Section 3 Basic Programming and Operation
3-15
2. Press softkey A, MORE.
3. Press number 4, MULTI PUMP. The multi-pump menu
will appear.
4. Press number 1 for pumps A or B, press number 2 for
pumps C or D.
5. Press number 4, INDEPENDENT. The controller will set
the pumps to Independent mode. Number 4 will blink,
indicating that INDEPENDENT mode is selected.
6. Select the HOLD PRESS or NORMAL mode of operation.
Press softkey A to toggle between the two modes.
HOLD PRESS: In constant pressure mode, after the
pump is empty, if the outlet pressure rises past the set
point the pump will restart and run the system to the set
point pressure.
NORMAL: This feature shuts the system down if a pump
runs empty in constant pressure mode.
Once the pumps have been set to this mode, they will
operate independently from one another. Each pump will
operate at its defined limit and rate. Independent mode is
the default setting for the pump.
When you select a command such as STOP or REFILL, the
display will prompt you to designate which pump to stop or
refill. Only the designated pump will stop; the other pumps
will continue to run.
Note
In an emergency situation, toggling the On/Standby switch will
cause all pumps to immediately stop.
7. Return to the run screen by pressing D three times. Then
press D (SELECT PUMP). The display will show each pump’s
information and allow you to select any pump for program-
ming changes.
3.10 Operating Modes The pump has three delivery modes and one refill mode.
Note
When using a single controller to operate multiple pumps inde-
pendently, you need to select the appropriate pump run screen
before selecting a mode. To select the appropriate pump,
press SELECT PUMP (D) and an intermediate screen will be
shown. Press the softkey for the appropriate pump, the run
screen for that pump will appear.
Constant Flow – Refer to Section 3.10.1
This mode is used when the flow rate must remain constant
during the pumping operation.
Constant Pressure – Refer to Section 3.10.2
