UDB-9000 Universal Deck Box - UDB-9000-M (Portable) and UDB-9000-MR (Rack Mount) Configurations 2-1
2 Specifications General
2 Specifications
This section provides specifications for the UDB-9000 Universal Deck Box.
All specifications are subject to change without notification.
General
Acoustic Telemetry Modem
Frequency band: 9–14 kHz (LF), 16–21 kHz (MF),
25–30 kHz (HF), or 22–27 kHz (Band C)
Data modulation: PSK and MFSK
Baud rate: 2560–15,360 bits/sec (PSK transmit and
receive); 140–2400 bits/sec (MFSK transmit
and receive)
Addressable modems: 100
Processing features: Data redundancy
1/2 rate convolutional coding
Multipath guard period
Serial interface: RS-232/422 (COM1)
RS-232 (COM2)
Transponder
Frequency band: 7–16 kHz (LF), in 250-Hz steps
Receive frequencies: Multi-receive all frequencies across band
FSK commands: A–M
Transmit pulse width: 10.0–25.0 ms, user selectable
Receive pulse width: 5.0–15.0 ms, user selectable
Turn around time: 0.0–99.9 ms, user selectable
Timeout: 2.0–99.5 s, user selectable
Ping lockout: 0.0–995.0 ms, user selectable
Data log file size: 1 MB
