6325 Edge Node 3 Reference Information
Balun items The following balun items are available for the Tellabs 6325 node.
SDH/PDH Interface
cables
The following optical and electrical interface cables are available for the Tel-
labs 6325 node.
Description Item number
RJ-45 to 1.0/2.3 (female) cable with 120/75 ohm
balun inside for 2 Mbit/s interface on SPIMX
module.
WK-508B-01.0-01
120/75 ohm balun, 3 pole IDC (Krone) to BNC
connector
WK-511B-KIT
Description Item number
Optical single mode fiber cables, two fibers in one cable
2xLC to 2xLC single mode fiber cable, 5 m W-OF203/05.0
2xLC to 2xLC single mode fiber cable, 10 m W-OF203/10.0
2xLC to 2xLC single mode fiber cable, 20 m W-OF203/20.0
2xLC to 2xFC/PC single mode fiber cable, 5 m W-OF204/05.0
2xLC to 2xFC/PC single mode fiber cable, 10 m W-OF204/10.0
2xLC to 2xFC/PC single mode fiber cable, 20 m W-OF204/20.0
2xLC to 2xSC single mode fiber cable, 5 m W-OF205/05.0
2xLC to 2xSC single mode fiber cable, 10 m W-OF205/10.0
2xLC to 2xSC single mode fiber cable, 20 m W-OF205/20.0
Electrical cables
1.0/2.3 to 1.0/2.3 coaxial cable, 5 m WK-482B-05.0-01
1.0/2.3 to 1.0/2.3 coaxial cable, 10 m WK-482B-10.0-01
1.0/2.3 to 1.0/2.3 coaxial cable, 20 m WK-482B-20.0-01
1.0/2.3 to BNC coaxial cable, 5 m WK-483B-05.0-01
1.0/2.3 to BNC coaxial cable, 10 m WK-483B-10.0-01
1.0/2.3 to BNC coaxial cable, 20 m WK-483B-20.0-01
1.0/2.3 to 1.6/5.6 coaxial cable, 5 m WK-484B-05.0-01
1.0/2.3 to 1.6/5.6 coaxial cable, 10 m WK-484B-10.0-01
1.0/2.3 to 1.6/5.6 coaxial cable, 20 m WK-484B-20.0-01
1.0/2.3 to open ended coaxial cable, 20 m WK-497B-20.0-01
MDR to open ended cable, 120 ohm, 5 m WK-503Y-05.0-01
MDR to open ended cable, 120 ohm, 10 m WK-503Y-10.0-01
