6325 Edge Node 3 Reference Information
Synchronization function
in free-running mode
The following table describes the specifications for the synchronization func-
tion in free-running mode.
3.5.4 Management Interfaces
Management protocol
stack
Specification of the management protocol stack.
Note: (1) Proprietary protocol
Note: (2) A limited but compatible version
Parameter Reference SETG output
Frequency Stability
Frequency offset EN 300 462-5 +/- 4.6 ppm for ap-
proximately 10 years.
A software option will
allow in system recali-
bration.
Craft Terminal In-
terface
Ethernet ECC Channels
Connection type co co/cl co/cl
Layer
Application LMIP (1) LMIP (1) LMIP (1)
Presentation - - -
Session---
Transport NTH(1) TP4:
X.224, X.214
(class 4)
(ISO 8073)
TP4:
X.224, X.214
(class 4)
(ISO 8073)
Network - CLNP: ISO 8473
Addr: ISO
8348:AD2
ES-IS: ISO 9542
IS-IS: ISO 10589
(2)
CLNP: ISO 8473
Addr: ISO
8348:AD2
ES-IS: ISO 9542
IS-IS: ISO 10589
(2)
Data link S-link(1) LLC-1
ISO 8802-2 Type
1
Q.921
LAPD
Physical V.28
9600 baud
CSMA/CD
ISO 8802-3
DCC-R, DCC-M,
F2, VC-12
