60 MA365 Rev. A2
Tellabs
®
6325 Edge Node 3 Reference Information
Auxiliary alarm I/O's The system is equipped with 4 auxiliary alarms I/O circuits AUX0-AUX3. The
following table depicts the interface specifications for these interfaces.
For configuration of the AUX ports, please refer to the manual for Tellabs 6300
manager [1].
3.5.5 Power
AC input The table lists the AC power specifications.
Secondary supply Dual DC supply with dual PS-DC module. One supply can be used as protec-
tion supply for the other. The PS-DC module (CM3561) can provide maxi-
mum 75 W to the internal +13.5 V power distribution net, refer to the descrip-
tion in ‘Power system description’ on page 50.
The DC input must be protected by a minimum 3 A, maximum 10 A, 125 VDC
rated protection fuse.
Power consumption The power consumption of the different types of modules are shown in the
following table.
Signal Description Interface
AUX 2-way configurable control
signals
3V CMOS level. Can source
and sink 10 mA as output
Parameter Value
Nominal Voltage 115 or 230 VAC
Rated Voltage 90 to 264 VAC
Input Frequency 47 to 63 Hz
Fuse Internal 3 A
Power consumption max. 130 W
Parameter Value
Nominal voltage -48 V or -60 V
Rated voltage -40.5 V to -72 V
Power consumption max. 90 W
Module Power consumption (W)
CM3563 (SPIMX) 6.5
CM3564 (CMCC) 1.5
CM3565 (Fan) 5.1
CM3566 (PIM1) 4.2
CM3567 (SIMX4) 6.4
