MA365 • Rev. A2 37
Tellabs
®
6325 Edge Node 2 Installation Information
Warning Please note the following warning.
2.8 Removing a Module from the Subrack
To remove a module
from the subrack
Please follow this procedure when you have to remove a module from the
subrack. This procedure has to be followed removing all types of modules.
Warning: The Tellabs 6325 node will be reset if this procedure is not followed.
Note: To avoid damage on components sensitive to static electricity, use an
antistatic bracelet connected to the chassis of the Tellabs 6325 node.
3 Connect the AC power cable to the AC/DC adapter.
Note: The AC power cable is not supplied with the AC/DC adapter.
Step Action
Step Action
1
Disconnect all cables connected to the module.
2 Unscrew the two screws that fasten the module to the subrack.
3 Push the switch (Remove) on the module using the reset tool and
wait for the LED (Safe Removal) to switch on.
To Next Page
