6325 Edge Node 3 Reference Information
Test sequence in use The table specifies the test sequence for in use.
Functional tests are made during and at the end of each test to verify that per-
formance parameters are fulfilled.
3.5.8 EMC Conditions
Compliance The principal protection requirements of the EMC Directive 89/336/EEC are
satisfied.
Test specifications Verification of compliance with conditions is done by testing in accordance
with EN 300 386: Telecommunication Network Equipment, EMC require-
ments. Sub clause 7.2 Equipment operating in locations other than telecom-
munication centres.
EMC emission tests The table shows the EMC emission test specifications.
Parameter Severity Reference
Low temperature when AC powered
-5 ° C, 16 h
when DC powered
-40 ° C, 16 h
IEC 60068-2-1 Ad
High temperature when AC powered
55 °C, 16 h
when DC powered
70 °C, 16 h
IEC 60068-2-2 Bd
Temperature change -40/45 ° C, 1 ° C/min
t1 = 3 h, 2 cycles
IEC 60068-2-14 Nb
Mechanical shocks
30 m/s
2
, 11 ms, 6 x 3
shocks
IEC 60068-2-27 Ea
Vibration,
sinusoidal
5 - 62- 200 Hz,
1.5 mm - 2 m/s
2
3 x 5 sweep cycles
IEC 60068-2-6 Fc
5 - 9 - 200 Hz,
1.2 mm - 4 m/s
2
3 x 5 sweep cycles
Humidity,
condensation
25/40 ° C, 90-100%RH,
2 days
IEC 60068-2-30 Db 1
High humidity 35 ° C, 93%RH, 4 days IEC 60068-2-56 Cb
Phenomenon Limits Reference
Enclosure Ports:
Electromagnetic Field
30-1000 MHz, 10m
30 - 230 - 1000 MHz
30 - 30/37 - 37 dBµV/m
EN 55022
Class B
AC Power Supply Ports:
