Tellabs 6325 - Page 72

72 MA365 • Rev. A2
Tellabs
®
6325 Edge Node 3 Reference Information
EMC immunity tests for
DC power supply ports
Specifications for DC power supply ports.
EMC immunity tests for
signal and control ports
Specifications for signal and control ports.
Surge Transients
rise time 1.2µs
decay time 50µs
1 kV line to line
2 kV line to
ground
B EN 61000-4-5
2 kV line to line
4 kV line to
ground
R
Phenomenon Test Level Performance Reference
Phenomenon Test Level Performance Reference
Voltage Variations
and Short Interrup-
tions
40.5 - 57.0 V
50.0 - 72.0 V 5V/
ms
A ETS 300 132-2
0 V in 4 ms A
0 V in 50 ms C
Radio Frequency
CM Voltage
0.15 – 80 MHz
80 % AM, 1 kHz
10 V B EN 61000-4-6
EN 300 386,
sub clause
12.2.2
Fast Transients
rise time 5ns
decay time 50ns
1 kV B EN 61000-4-4
2 kV C
Surge Transients
rise time 1.2µs
decay time 50µs
0.5 kV line to line
0.5 kV line to
ground
A EN 61000-4-5
0.5 kV line to line
1 kV line to
ground
A (only with
external surge
filter
1 kV line to line
2 kV line to
ground
B (only with
external surge
filter
0.5 kV A ITU-T K.20
Phenomenon Test Level Performance Reference
Radio Frequency
CM Voltage
0.15 – 80 MHz
80% AM, 1kHz
10 V B EN 61000-4-6
EN 300 386,
sub clause 12.2.2
Fast Transients
rise time 5ns
decay time 50ns
0.5 kV B EN 61000-4-4
1 kV C
