TM SERIES
1-11
TM Series Terex South Dakota, Inc. 472797 - 1/15
OPERATION GUIDELINES
2. Engine Stop/Start
(Optional)
Push and hold to start engine.
Release when engine starts.
Push and release to stop engine.
Can also be used to stop the Aerial Device in an
emergency.
3. Two-Speed
Throttle
*Auxiliary Let
Down Power
(Optional)
With engine running, the throttle is activated.
Push and release to increase engine RPM.
Push and release to return to engine idle.
With engine “OFF”, the auxiliary let down power is activated.
Push and hold to turn on auxiliary let down power.
Release to shut off auxiliary let down power.
NOTE: *Can be included with two-speed throttle circuit. When vehicle engine is disabled,
the auxiliary let down power can be activated by the two-speed throttle switch.
NOTE: *Do not operate longer than 30 seconds. Continuous operation will drain battery
and/or overheat pump motor.
4. Hydraulic Tools
(Optional)
Push to select tool circuit number 1.
Turn tool “OFF” before operating other functions.
Pull to select tool circuit number 2, if equipped.
5. Stop Push to stop all operations at the platform controls. This
diverts all oil to the tank.
Pull to resume operation.
6. Jib Articulation
(Optional)
Push to lower jib boom “DOWN”.
Pull to raise jib boom “UP”.
ENGINE
PUSH/RELEASE
STOP/START
437033
DC POWER
PUSH/HOLD
457452
THROTTLE
PUSH/RELEASE
TWO SPEED
431560B
TOOL 2
TOOL 1
457447
TOOLS
0
0
5
2
4
4
A
PUSH
EMERGENCY
STOP
JIB
ART
UP
DOWN
