OPERATION GUIDELINES
1. Top Control Shut-
Off
Pull up to turn “ON”.
Push down to turn “OFF”.
Must be in the “ON” position to operate the jib, winch,
platform rotate and hydraulic tools at the platform location.
2. Lower Boom Push lever forward to “RAISE” lower boom up.
Pull lever back to “LOWER” lower boom down.
3. Boom Rotation Push lever forward to rotate booms to the right or
counterclockwise “CCW”.
Pull lever back to rotate booms to the left or clockwise “CW”.
