TM SERIES
1-16
472797 - 1/15 Terex South Dakota, Inc. TM Series
OPERATION GUIDELINES
4. Upper Boom Push lever forward to “LOWER” lower boom down.
Pull lever back to “RAISE” lower boom up.
Upper Boom
(TM125 only)
Pull lever back to “RAISE” lower boom up.
Push lever forward to “LOWER” lower boom down.
5. Platform Level Push lever to “LEVEL” platform.
Pull lever to “DUMP” platform.
Do not operate with personnel in the platform.
6. Winch (Optional) Push to lower load “DOWN” or pay-out winch line.
Pull to raise load or wind winch line “UP”.
DOWN
UP
WINCH
P475427B
