Lubrication and Servicing
8-11
* - Capacities given are approximate, work to dipstick, sight gauges or level plugs.
Note 1 - The use of low viscosity oils, such as 10W-30 or 5W-30, can be used to aid in starting the engine and
providing sufficient oil flow at low ambient temperatures. Continuous use of low viscosity oils can decrease
engine life due to adverse wear.
Note 2 - Operation below the minimum temperatures listed for the oil used without proper preheat or warm-up
results in greatly reduced transmission life. Proper warm-up requires 20 minutes minimum operation in neutral
(with engine at part throttle) before operating the transmission in gear.
Note 3 - Hydraulic Transmission Oil meeting Specification EMS19058 is suitable for use in the hydraulic sys-
tem.
Note 4 - Automatic Transmission Fluids (ATF) may only be used when the ambient temperature is less than -
10° C (14° F). Should the temperature increase, it is necessary to switch to engine oil.
Note 5 - Maximum 1.5% of Lubrizol (TEREX Part No. 15250489), may be added to planetary capacity to pre-
vent brake squeal.
Any increase in the stated volume of Lubrizol will result in a decrease in brake performance.
Note 6 - Volume of Lubrizol to each planetary is as follows:
Front: Maximum 1.5% = 165 ml (5.57 oz)
Centre and Rear: Maximum 1.5% = 110 ml (3.71 oz)
RECOMMENDED LUBRICANTS
COMPONENT LUBRICANT *CAPACITY SPECIFICA-
TIONS
API
CODE
SAE GRADE
Engine (Including
Filters)
Engine Oil with 1.00% sulphated ash limit is rec-
ommended. Sulphated ash must not exceed
1.85% limit
32 Litres (9.8 US gal) CH-4 15W-40
Transmission
(Including Filters)
(dry fill)
TranSynd / TES295
61 Litres (16.1 US gal)
TranSynd /
TES295
-See Trans.
TES 295
Oil Table.
Hydraulic System
(Including Lines)
Hydraulic Transmission Oil
330 Litres (87 US gal) Textran
HD10
See Hydraulic Oil Table
(See Note 3)
Cooling System Anti-freeze, Ethylene Glycol
67 Litres (18 US gal)
Differential
(
Front)
Extreme Pressure Gear Lubricant
33 Litres each (8.7 US
gal)
MIL-L-2105 D
(See Note 4)
GL-5 80W-90 LS
Differential
(Centre)
Extreme Pressure Gear Lubricant
34 Litres (9 US gal)
MIL-L-2105 D
(See Note 4)
GL-5 80W-90 LS
Differential
(Rear)
Extreme Pressure Gear Lubricant
33 Litres each (8.7 US
gal)
MIL-L-2105 D
(See Note 4)
GL-5 80W-90 LS
Planetaries Extreme Pressure Gear Lubricant
9 Litres each (2.4 US gal)
MIL-L-2105 D
(See Note 4)
GL-5 80W-90 LS
Dropbox Engine Oil
13 Litres (3.4 US gal)
CH-4 15W-40
Fuel Tank Diesel Fuel Oil with max. sulphur 0.5%
481Litres (127 US gal)
DIN EN590
Grease Nipples** Extreme Pressure Lithium Grease No.2
Consistency
Drive shaft through
Bearings
Extreme Pressure Gear Lubricant 1.5 Litres (0.40 US gal) MIL-L-2105 GL-5 80W-90
Articulation Bearings Extreme Pressure Lithium Complex EMS 19057
Air Conditioning
Compressor
Poly alklene Glycol (PAG) Compressor Lubricat-
ing Oil - Low Viscosity
0.125 Litres (0.033 US gal) ISO46 SP 10
Brake Cooling
System
UTTO (Universal Tractor Transmission Oil) (Refer
to ZF Approved List)
175 litre
42.6 US gal)
(SAE) J2360
ZF 03E,
05F
10W-30
