Controls and Operating
3-37
MCU ERROR CODES
Error Code Description of Error Check
01 DASHBOARD DISPLAY- DASH NOT LIVE
02 ECU NOT LIVE
03 TCU NOT LIVE
04 Control Stock- LEVER NOT LIVE
05 ---------------
06 ---------------
07 ---------------
08 ---------------
09 ---------------
10 ---------------
11 MCU OUT_00 X1:18 SHORT K2_MainRelayTerminal15_ON
12 MCU OUT_00 X1:18 BREAK K2_MainRelayTerminal15_ON
13 MCU OUT_01 X1:17 SHORT E5_ParkingLights_ON
14 MCU OUT_01 X1:17 BREAK E5_ParkingLights_ON
15 MCU OUT_02 X1:16 SHORT E5_LowBeam_Left_ON
16 MCU OUT_02 X1:16 BREAK E5_LowBeam_Left_ON
17 MCU OUT_03 X1:15 SHORT E5_Indicators_LEFT_ON
18 MCU OUT_03 X1:15 BREAK E5_Indicators_LEFT_ON
19 MCU OUT_04 X1:14 SHORT E7_BrakeLights_ON
20 MCU OUT_04 X1:14 BREAK E7_BrakeLights_ON
21 MCU OUT_05 X1:13 SHORT K15_FrontWiper_Speed_1_ON
22 MCU OUT_05 X1:13 BREAK K15_FrontWiper_Speed_1_ON
23 MCU OUT_06 X1:12 SHORT K15a_FrontWiper_Speed_2_ON
24 MCU OUT_06 X1:12 BREAK K15a_FrontWiper_Speed_2_ON
25 MCU OUT_07 X1:11 SHORT E8_Indicators_RIGHT_ON
26 MCU OUT_07 X1:11 BREAK E8_Indicators_RIGHT_ON
