Safety
2-24
Safety Decals Set ANSI Standard
15343325
Remove ignition key
and wait for
2 minutes.
Switch off master
switch.
NOTICE
MOT00341
15370752
Crush Hazard.
Always adjust seat and fasten
seat belt. This nachine is
equipped with a Roll Over
Protection System (ROPS).
Keep all body parts inside
operator's cab at all times.
Ejection can result in
death or serious injury.
WARNING
MOT00340
Crush Hazard Warning - Seat Belt
15332782
CAUTION
NOTICE OF ROPS & FOPS CERTIFICATION
This structure meets the following requirements
for the machine and weights listed:
ROPS FOPS MAX. WEIGHT
SAE ISO
J1040 3471/1
SAE ISO
STRUCTURE
PART No.
J1043 3449
lb
33069
kg
15000 TA25/27
TA30
TA35/40
TA350/400
TA250/300
15502380
MODEL
MANUFACTURED FOR/BY
TEREX EQUIPMENT LTD. - SCOTLAND
Damage to ROPS may
weaken structure
and may cause injury.
If damaged, ROPS
must be replaced.
Do not repair.
Unauthorised modification
will void certification.
Tighten fastners
periodically.
B C
ROPS and FOPS Certification (1812)
N
15333272
Crush Hazard.
Sudden and unwanted
machine movement can
result in serious
injury or death.
Always ensure when
starting / stopping
engine to :
1. Apply park brake.
2. Shift transmission
into neutral.
P
1.
2.
WARNING
Park Brake Warning (1817)
Fall Hazard
Falling can result in death
or serious injury.
Do not work on this machine
without safety harness
and lanyard.
15356708
WARNING
Fall Hazard Warning (2220)
15333273
Injection Hazard.
Escaping fluid under pressure
can penetrate skin, resulting
in serious injury.
Relieve pressure before
disconnecting hydraulic lines.
Keep away from leaks and pin
holes. Use a piece of
cardboard or paper to search
for leaks. Do not use hand.
Fluid injected into skin must be
surgically removed within a few
hours by a doctor familiar with
this type of injury or gangrene
will result.
WARNING
Skin Injection Warning (1818)
15333278
Burn Hazard.
Hot fluid under
pressure can scald.
Allow to cool before
opening.
WARNING
Hot Radiator Steam Warning (1823)
15333277
Burn Hazard.
Contact with hot
surfaces can
result in burns.
Do not touch.
Allow surfaces to
cool before
servicing.
WARNING
Hot Surface Warning (1822)
Gradeability Chart (2168)
WARNING
15354036
L
H
%%
KPH
MPH KPH MPH
TA350/400
0 6 39 24 0 6 39 24
066037066037
5 4 28 17 5 6 60 37
5 5 28 17 5 6 39 24
20 2 7 4 20 3 15 9
25 2 6 4 25 3 12 7
15 2 9 6 15 4 21 13
10314 91053220
30 1 5 3 30 2 9 6
15 2 9 6 15 3 21 13
25 1 6 4 25 2 12 7
20 1 7 4 20 2 15 9
30 1 5 3 30 2 9 6
Operating the
truck outside
the stated limits
on the chart
could result in
death or serious
injury.
Do not operate
truck outside
the limits stated
on the chart.
Select the correct
gear for the
gradient you are on.
10 2 14 9 10 4 32 20
15333265
WARNING
Crush Hazard
Death or serious
injury may result.
Install support
before servicing.
Crush Hazard - Install support (1812)
