Fuse Name Size Function
F1 80A Master Fuse Terminal 30
F2 80A Master Fuse Terminal 30
F3 80A Master Fuse Terminal 15
F4 80A Master Fuse Terminal 15
F5 3A Not Connected
F6 7.5A Transmission Controller
F7 2A Emergency Operation
F8 15A Spare
F9 5A Interior Light
F10 7.5A Hazard Warning
F11 15A DC-DC Convertor
F12 7.5A Telematics Interface
F13 15A Work Socket 24V
F14 10A Air Seat Compressor
F15 5A Hydraulic Oil Sensors
F16 20A Fuel Heater
F17 20A Engine Management System
F18 2A Main Controller
F19 15A Main Controller
F20 25A Spare
F21 20A Engine Management System
F22 2A Main Controller / Ignition Lock
F23 15A Main Controller
F24 7.5A Spare
F25 2A Programming Interface
F26 15A Hood Lift
F27 3A Sensor Front Frame
F28 15A Main Controller
F29 5A Spare
F30 3A Rocker Switches
F31 15A X39.3 (Reserve Cabin)
F32 10A Not Connected
