Maintenance
TA9 & TA10 Dumper 0803-3 December 2010 9-18
Hubs
The hubs on the axles have separate oil cavities and the oil and
levels should be checked at the recommended intervals.
To Check The Level
• Position the machine on level ground with the words “OIL
LEVEL” (A) the correct way up and the line (B) horizontal.
• Clean dirt from around the plug (C).
• Remove the oil level plug.
• The oil level should be level with the bottom of the oil level
plug hole.
• Add the specified oil, as required, through the plug hole
until the oil begins to run out of the plug hole. See
Lubrication Points and Lubricants section for correct oil.
• Refit the plug and tighten.
